Description

The Orion XS, engineered from the ground up, redefines DC-DC battery-to-battery charging. Ideal for dual battery systems charged by an intelligent alternator.

This device not only ensures top-tier performance but also guarantees the safety of your system.

Stay in charge with configurable input and output currents and rest assured that your Orion XS will run at full capacity up to 40°C. The 98,5% efficient aluminium circuit board technology means less heat, without the need for fans.

As an integral part of your Victron system, the Orion XS offers full (remote) monitoring and control capabilities, giving you complete command of your device and system.

Features
Orion XS model with EMC improvements – recommended for marine use as well as for other applications with VHF radios
Parallel to increase output current
Smart alternator compatibility
Adaptive charge algorithm
Complete electronic protection
Low temperature shutdown & under voltage protection
Dust & waterproof

Specifications
Imput voltage range: 9-17v
Output voltage adjust range: 10-17v
Output voltage tolerance: +/- 0.25% (max)
Output voltage noise: 10 mV rms
Input and output current setting range: 1–50A
Maximum constant short-circuit current: 50A
Continuous output power up to 40 °C 1): 700 W
Maximum efficiency: 98.5 %
No-load current consumption: <100mA
Standby current consumption: <1.5mA
Can be used as power supply: Yes, output voltage can be set with VictronConnect App
Dimensions: 137.3 x 123.1 x 40 mm (HxWxD)
Shipping: Weight: 0.330 kg
Warranty: This product comes with a 5 year warranty
