Description

Features

Bluetooth Smart enabled for monitoring and updates.
Fully programmable with a battery charge algorithm or fixed output.
Suitable for vehicles with smart alternators.
Adaptive 3-stage charge algorithm: bulk – absorption – float.
Remote on/off capability.
High temperature protected.
IP43 protection when installed with screw terminals oriented downwards.
Specifications
Input voltage range: 8-17 V
Under voltage shutdown: 7V
Under voltage restart: 7.5 V
Nominal output voltage: 12.2 V
Output voltage adjust range: 10-15 V
Continuous output current at 40°C: 18 A
Maximum output current (10 s) at nominal output voltage minus 20%: 25 A
Short circuit output current: 40 A
Continuous output power at 25°C: 220 W
Continuous output power at 40°C: 280 W
Efficiency: 87%
No load input current: < 80 mA
Standby current: Less than 1mA
Galvanic isolation: 200 VDC between input, output, and case
Operating temperature range: -20 to +55°C (derate 3% per °C above 40°C)
Humidity: Max. 95% non-condensing
DC connection: Screw terminals
Maximum cable cross-section: 16 mm² AWG6
Weight: 1.3 kg
Dimensions (HxWxD): 130 x 186 x 70 mm
