Description

Features

Bluetooth Smart enabled for monitoring and updates.
Fully programmable with a battery charge algorithm or fixed output.
Suitable for vehicles with smart alternators.
Adaptive 3-stage charge algorithm: bulk – absorption – float.
Remote on/off capability.
High temperature protected.
IP43 protection when installed with screw terminals oriented downwards.
Screw terminals for easy installation.
All models are short circuit proof and can be paralleled to increase output current.
Specifications
Input voltage range: 10-17 V
Under voltage shutdown: 7V
Under voltage restart: 7.5 V
Nominal output voltage: 12.2 V
Output voltage adjust range: 10-15 V
Continuous output current at 40°C: 30 A
Maximum output current (10 s) at nominal output voltage minus 20%: 40 A
Short circuit output current: 60 A
Continuous output power at 25°C: 360 W
Continuous output power at 40°C: 430 W
Efficiency: 87%
No load input current: < 80 mA
Standby current: Less than 1mA
Operating temperature range: -20 to +55°C (derate 3% per °C above 40°C)
Humidity: Max. 95% non-condensing
DC connection: Screw terminals
Maximum cable cross-section: 16 mm² AWG6
Weight: 1.8 kg
Dimensions (HxWxD): 130 x 186 x 80 mm
