Description

Features

VE.Direct communication port for advanced monitoring and configuration.
Comprehensive adjustable settings, including dynamic cut-off and output voltage.
Established reliability with full bridge plus toroidal transformer topology.
High start-up power to cater to a diverse range of loads.
ECO mode for optimal energy efficiency.
Remote on/off capability.
LED diagnosis for straightforward troubleshooting.
Specifications
Continuous power at 25°C: 2400W (for the 24/3000 model)
Peak power: 6000W
Output AC voltage/frequency: 230VAC +/- 2%, 50Hz or 60Hz +/- 0.1%
Input voltage range: 18.6 – 34V
Dynamic cut-off: Configurable
Max. efficiency: 94%
Zero-load power: 13W
Zero-load power in ECO mode: 1.9W
Protection features: Output short circuit, overload, battery voltage too high/low, temperature too high, 230 VAC on inverter output, input voltage ripple too high.
Operating temperature range: -40 to +65°C (fan-assisted cooling)
Humidity: Max. 95% non-condensing
Material & Colour: Steel chassis and plastic cover (blue RAL 5012)
Battery connection: M8 bolts
Weight: 19kg
Dimensions (HxWxD): 533 x 285 x 150 mm
Protection category: IP 21
