BatteryPlus35-II-HA (High Amp Power Management System)

  • Total output current 35A
  • 30A multistage battery charger
  • Inbuilt solar MPPT regulator (420W, 30A, 25V max input)
  • Distribution board with 12 at 10A and 2 at I5A DC outputs for load connection
  • Electronic resettable fuses
  • CAN bus connection for BMPRO accessories
  • Solar and Aux Blending
  • Auxiliary DC input
  • Load current limit
  • Low voltage disconnect
  • Compatible with lead acid and lithium (LiFePO4) deep-cycle batteries

$1,149.00

AUD

Zip-logo-16-9-e1626913893928
Afterpay_Logo_Mint-1
CREDIT CARD
Part Number BatteryPlus35-II-HA Category Brand:

Description

Australian designed and made high amp Power Management System compatible with lead acid and lithium batteries

BatteryPlus35-II-HA is a complete high amp Power Management System designed to support transition of caravans to lithium batteries. This all in one power solution combines a 35A power supply for 12V loads, 30A multi-stage AC charging and 30A Solar MPPT regulation as well as a host of battery protection features.

Connect the unit via CAN bus to the Trek battery monitor or to Odyssey touch screen via the OdysseyLink to monitor the status of your battery and to control your caravan features and functions or use it to connect to the BC300 to monitor high currents via CommLink.

BatteryPlus35-II-HA is pre-cabled with a permanent mains power supply cord for use with 240V or 110V input power – great for powered sites.

The unit also features a 40A rated uncontrolled +BRK battery output. This output is specifically designed for loads which do not need to be isolated or have a current rating of higher than the inbuilt circuit protection of the individual outputs and have a current rating less than 40 A.

Use it to connect, for example:
• Proactive Electronic Stability Control SwayControl
• Emergency Trailer Break-Away Safety System TrailSafe
• Heaters
• Stereo memory

Designed and manufactured in Australia, the slim and sturdy BatteryPlus35-II-HA is fully equipped to charge the current generation of deep cycle batteries. Connect solar panels to the Power Management System and power your adventures with renewable energy. Swap your caravan battery to the LiFePO4 deep cycle and harness the benefits of lithium. This high amp Power Management System is specially designed to ensure the best performance and longevity of lithium batteries.

Specifications

Input Voltage Range

110V – 240V AC ± 10%, 50-60Hz

Input Surge

<40A (cold start)

Output Current (Load + Battery Current)

35A

Factory Set Voltage (Float Voltage)

13.65V

Output Ripple Voltage

<150mV

Battery Current Limit

max. 30A

Low Voltage Disconnect

Lead-acid: 10.8V ± 0.2V

LiFePO4: 12.0V ± 0.2V

Battery Connect after LVD

Lead-acid: 12.8V ± 0.2V

LiFePO4: 13.8V ± 0.2V

Battery Drain (when in Storage Mode)

<15mA

AC/DC Efficiency

>83%

Cooling Fan

Digitally controlled

Maximum Solar Input

800W

Solar Output Current

30A (nominal)

Solar Start Voltage

17.5V

Solar Input Voltage (After Start-up)

15V – 25V

Ambient Temperature

0°C to 50°C

Communication

CAN Bus

Dimensions

327mm x 207mm x 82mm

Weight

2kg

Standards

Safety: AS/NZS 60335.2.29, UL 458, UL 1741
EMC: AS/NZS CISPR 32, FCC Part 15
Approvals: RCM, UL, FCC
