Description

Introducing our VanLiFe range of lithium batteries.
Active and passive cell balancing.
Cable free internal construction ensures higher performance and reliability.
Automotive grade cells IEC 62619 certified.
Laser welded bus bar connections to the cell pack ensure lower resistance compared to bolted studs, while also offering superior strength.
Sealed zinc plated and powder coated steel enclosure with vent outlet satisfying the requirements of the new AS/NZS3001.2:2022 standards for installation.
High + Low temperature and voltage protection plus over current protection as required by AS/NZS3001.2:2022 standards for installation.
7 + 3 year warranty with after warranty repair service available.
Designed and hand built in Australia.

Individually twice QC checked and tested.

LiFePO4 12.8v Suitable for “12v” systems

BMS continuous discharge: 300A

BMS continuous charge: 300A

BMS over current protection: 320A for 10 seconds, reset 35 seconds.

Low voltage discharge shut down: 10v restart 10.5v

High Voltage charge disconnect: 15v restart 14.8v

Low temp charge disconnect: 1c reset 2c

Low temp discharge disconnect -20c reset -15c

High temp charge disconnect: 55c reset 50c

High temp discharge disconnect: 60c reset 55c

Charging

Bulk Charge: 14.2V – 14.6V (ideal: 14.4V)

Absorption: 14.2V – 14.6V (ideal: 14.4V)

Float: 13.4V – 13.6V (ideal: 13.5V)

The Automotive grade cells used are rated 8000 cycles @ 70% DOD

Terminal size: M10

Vent outlet thread: 1/2 inch male BSP thread

Sealed back riveted case made from zinc plated and powder coated steel with high temp sealant

Weight 54.5kgs
